Machine Description
The Motorized Sheet Rolling Machine is a
powerful and precision-engineered solution
designed for rolling metal sheets into
cylindrical or curved shapes. Suitable for sheet
thicknesses ranging from 1mm to 6mm and
working widths up to 1250mm (customizable),
this machine is ideal for fabricators,
automotive manufacturers, ducting units, and
heavy metal processing units. Powered by a
robust 3 HP 3-phase motor with a gearbox
and controlled by a Variable Frequency Drive
(VFD), the machine delivers smooth,
adjustable rolling speeds with superior control
and torque.
Features
• Motorized operation with smooth and consistent rolling performance
• Handles sheet thickness from 1mm to 6mm (custom thickness on request)
• Rolling width up to 1250mm (customizable for wider sheets)
• Equipped with a 3 HP 3-phase motor and heavy-duty gearbox
• VFD (Variable Frequency Drive) for adjustable rolling speed and torque control
• Hardened rollers for long life and precise forming
• Rigid frame for stability under load
• Suitable for rolling SS, MS, aluminum, and alloy sheets
• Option to customize for higher thickness (up to 8–10mm) with enhanced motor and
gearbox setup
Technical Details
| Parameter |
Specification |
| Material Compatibility |
SS304, SS316, Mild Steel, Aluminum, Alloys |
| Sheet Thickness Range |
1mm to 6mm (customizable up to 10mm) |
| Rolling Width |
Up to 1250mm (customizable) |
| Drive System |
Motorized with Gearbox |
| Motor Power |
3 HP, 3-Phase AC |
| Speed Control |
VFD for Variable Rolling Speed |
| Roller Material |
Hardened Steel Rollers |
| Operation Type |
Semi-Automatic |
| Frame Type |
Heavy-duty Steel Fabricated |
| Optional Features |
Cone Rolling |
